All-Electric Servo CNC Bending MachinesPrecision Without Compromise Our all-electric servo CNC press brakes set a new standard in sheet metal bending, delivering unmatched accuracy, dynamic performance, and intelligent design for today’s manufacturing demands.
The machine features exceptional bending speed and precision, supported by an ergonomic design and modern industrial aesthetics for optimal user experience.
Equipped with a dual-servo drive system, high-performance large-caliber ball screws, and a wheel-guided mechanism, it ensures smooth and stable bending even under heavy workloads.
The machine body, including the ram, frame, and vertical plates, is built with high-end manufacturing technology to guarantee long-term durability and consistent motion accuracy.
The use of a large-diameter screw and self-aligning arc mechanism ensures smooth guidance and balance of the ram, even during off-center bending operations.
A closed-loop position control system with dual linear scales ensures high repeatability and exact positioning in every cycle.
The fully automatic lubrication system eliminates manual maintenance and keeps critical components in optimal condition for long service life.
A reliable, quiet, and oil-free solution designed for precision-focused production environments.
STANDARD FEATURES
•-Up to 35% lower energy consumption compared to conventional systems.
• Low noise levels during pressing and return strokes for a more comfortable working environment.
• Silent standby mode and high-speed downward motion for improved efficiency.
• Streamlined industrial design with refined European aesthetics
• High-precision Y1/Y2 positioning using optical or magnetic linear scales
• Closed-loop feedback system enables consistent and highly accurate bending results
• Fully electric servo drive system ensures fast response and maximum bending efficiency
• Y1, Y2, and X axes included as standard configuration
• Backgauge equipped with ball screw and linear guide for precise positioning.
• Linear scales on Y1 and Y2 axes by GIVI MISURE for excellent repeatability
• Premium SCHNEIDER-brand electrical components ensure long-lasting reliability.
• European-style punch and die holders for easy tool installation.
Dual-load ball screw structure ensures superior efficiency and precision by maintaining a rigid, tightly integrated connection between the bearing seat and the machine frame.
The dual grating ruler system ensures superior synchronization and structural stability, effectively preventing accuracy loss caused by guide rail wear.
| MODEL | Bending Force (kN) | Bending Length (mm) | Approach Speed (mm/s) | Working Speed (mm/s) | Return Speed (mm/s) | X-axis Stroke (mm) | Distance Between Columns (mm) | Throat Depth (mm) | Stroke (mm) | Open Height (mm) | Main Power (kW) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 10T/400 | 100 | 400 | 200 | 1-30 | 200 | 200 | 320 | 200 | 200 | 420 | 3.1 |
| 10T/500 | 100 | 500 | 200 | 1-30 | 200 | 200 | 450 | 175 | 200 | 420 | 3 |
| 12T/600 | 120 | 600 | 200 | 1-30 | 200 | 200 | 520 | 200 | 200 | 420 | 5.5 |
| 14T/500 | 140 | 500 | 200 | 1-30 | 200 | 200 | 450 | 175 | 200 | 420 | 5.5 |
| 14T/600 | 140 | 600 | 200 | 1-30 | 200 | 200 | 520 | 200 | 200 | 420 | 7.5 |
| 20T/1200 | 200 | 1200 | 200 | 0.15-50 | 200 | 200 | 920 | 250 | 150 | 420 | 2×5.5 |
| 40T/1600 | 400 | 1600 | 200 | 0.15-30 | 250 | 400 | 1250 | 255 | 150 | 420 | 2×15 |
| 60T/1600 | 600 | 1600 | 200 | 0.15-30 | 250 | 500 | 1600 | 300 | 200 | 470 | 2×20 |
| 80T/2500 | 800 | 2500 | 200 | 0.15-30 | 200 | 500 | 2000 | 460 | 200 | 470 | 2×25 |
| 100T/3200 | 1000 | 3200 | 200 | 0.15-30 | 200 | 500 | 2700 | 460 | 200 | 470 | 2×25 |
